G150XTN06.0 Basics
The AUO G150XTN06.0 LCD is a 15.0'' a-Si TFT-LCD display panel for reliable industrial display applications. Designed with an XGA resolution of 1024 × 768 pixels, it delivers clear and stable image performance suitable for control panels, embedded systems, and automation equipment. As a Color Active Matrix Liquid Crystal Display, the G150XTN06.0 integrates the TFT-LCD panel, driver circuit, and backlight system into a complete display solution.
Built with an LVDS interface, the G150XTN06.0 industrial LCD module ensures stable, high-speed signal transmission and broad compatibility with modern control boards. The module design complies with PSWG standards, allowing seamless integration into existing industrial systems. formance, stable operation, and dependable visual output.
G150XTN06.0 Specifications
Below is a table of common specifications for the G150XTN06.0 LCD panel, for reference.
TYPE | DESCRIPTION |
Brand | AUO |
Model | |
Size | |
Composition | a-Si TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 85PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 304.128(W)×228.096(H) mm |
Bezel Opening | 307.4(W)×231.3(H) mm |
Outline Size | 326.5(W)×253.5(H) ×12.5(D) mm |
Brightness | 450 cd/m² (Typ.) |
Contrast Ratio | 800:1 (Typ.) (TM) |
Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) |
Response Time | 5.7/2.3 (Typ.)(Tr/Td) |
Display Colors | 262K/16.2M 60% NTSC |
Lamp Type | WLED , 50K hours , With LED Driver |
Frequency | 60Hz |
Voltage Supply | 3.3V (Typ.) |
Panel Weight | 1.00Kgs (Max.) |
Signal Interface | · LVDS (1 ch, 6/8-bit) , 20 pins Connector |
Touchscreen | Without |
Max Ratings | Operating Temperature:-30 ~ 85 °C ; Storage Temperature: -30 ~ 85°C |
G150XTN06.0 Performance Characteristics
Display Performance
The G150XTN06.0 LCD features a 15.0-inch XGA (1024 × 768) resolution and supports 16.2M or 262K colors, so the panel offers consistent color reproduction suitable for professional environments. The response time is optimized for smooth interface transitions, while the viewing angles support standard horizontal and vertical visibility for front-facing installations.
Interface and Compatibility
The G150XTN06.0 uses an LVDS interface for stable, high-speed signal transmission with strong anti-interference capability. It integrates the driver circuit and backlight system, simplifying system design. Designed in compliance with PSWG standards, the module is compatible with a wide range of industrial control boards and embedded systems. With an external controller, it can also support VGA or HDMI input configurations.
Environmental Adaptability
Engineered for industrial applications, the G150XTN06.0 supports a wide operating and storage temperature range under industrial environments. When installed in protective enclosures, it can meet dust-proof and moisture-resistant requirements, making it suitable for long-term industrial deployment.
G150XTN06.0 Advantages and Benefits
The G150XTN06.0 15.0" industrial LCD screen combines durability with clear visual performance. Below is a concise summary of its key advantages and practical benefits for industrial and commercial use:
l Extreme Thermal Resilience: Designed to operate in harsh environments such as outdoor kiosks, cold storage units, and high-temperature factory floor.
l High-Efficiency WLED Backlight: Features a WLED backlight with a typical 70,000-hour lifespan and an integrated LED driver, ensuring long-term reliability and reduced maintenance costs.
l Superior Readability in Bright Environments: With 450 cd/m² brightness and an 800:1 contrast ratio, plus an anti-glare (3H hard coating) surface, the display remains clear under strong ambient or industrial lighting. This helps reduce eye strain and operational errors.
l Robust LVDS Interface: Equipped with a single-channel LVDS (6/8-bit) interface, providing stable, noise-resistant signal transmission in electrically noisy environments such as near motors or heavy machinery.
l Mechanical Stability: Built to withstand 1.5G vibration with a slim 12.0 mm profile, making it suitable for marine systems, agricultural vehicles, and heavy equipment displays.
G150XTN06.0 Application Scenarios
The G150XTN06.0 LCD panel is widely used in various industrial environments thanks to its high brightness, wide temperature design, and stable LVDS interface.
1. Industrial Automation and Production Line Control
In factory automation equipment, PLC control systems, and HMI (Human-Machine Interface) applications, the G150XTN06.0 is used to display real-time operating status, process parameters, and alarm information. Its 1024 × 768 resolution ensures clear presentation of data charts and control interfaces, while the high brightness and anti-glare design maintain excellent readability under strong industrial lighting conditions.
2. Industrial Control Cabinets and Embedded Terminals
In power control cabinets, inverter systems, and intelligent power distribution equipment, this panel can serve as a core display module integrated into embedded systems. The LVDS interface provides strong anti-interference capability, making it suitable for electromagnetically complex industrial environments and ensuring stable signal transmission without flicker.
3. Transportation and Outdoor Equipment
With strong temperature adaptability and mechanical stability, the G150XTN06.0 is suitable for outdoor information terminals, self-service kiosks, and railway or transit control systems. It maintains stable performance under extreme temperatures and vibration conditions, making it ideal for long-term deployment.
4. Construction Machinery and Special Vehicles
In agricultural machinery, construction vehicles, and marine bridge displays where high vibration is common, this panel functions as a reliable operation display interface. Its 1.5G vibration resistance and robust structural design allow it to withstand continuous shock and vibration, ensuring critical system information is displayed clearly and consistently.
G150XTN06.0 Packaging
Max capacity：15pcs TFT-LCD module per carton
Max weight: 18.5 kg per carton
Outside dimension of carton: 434(L) mm x 380(W) mm x 353(H) mm
Pallet size： 1140 mm * 890 mm * 135 mm
Palletizing
Module by air：(2 *3) *4 layers，one pallet put 24 boxes，total 360pcs module
Module by sea：(2 *3) *4 layers+ (2 *3) *1 layers , two pallet put 30 boxes，total 450pcs module
Module by sea_HQ：(2 *3) *4 layers+ (2 *3) *2 layers , two pallet put 36 boxes，total 540pcs module
FAQs
What is the G150XTN06.0?
The G150XTN06.0 is a 15.0-inch industrial-grade a-Si TFT-LCD panel with XGA resolution (1024 × 768). It is designed for industrial display applications requiring stable performance, durability, and long operational life.
What is the backlight type and lifetime?
The G150XTN06.0 features a WLED backlight system with a typical lifespan of up to 70,000 hours, offering long-term reliability and reduced maintenance requirements.
What applications is the G150XTN06.0 best suited for?
It is commonly used in industrial automation systems, control cabinets, medical equipment, transportation terminals, and heavy machinery display interfaces.
