The G190ETN01.4 is a 19.0'' TFT-LCD display module for industrial applications, launched by AU Optronics (AUO). As a large-sized industrial display solution, this product offers stable display performance and a reliable structural design. It meets the dual requirements of various professional equipment, for both display quality and durability.
This article will provide a detailed review of the G190ETN01.4's parameters, features, typical application scenarios, and more. It aims to provide engineers and purchasing personnel with clear and practical reference information.
G190ETN01.4 Overview
The G190ETN01.4 is a color active matrix liquid crystal display (TFT-LCD) module, primarily composed of a TFT-LCD panel, driver circuitry, and a backlight system. This module supports SXGA (1280 × 1024) resolution and can display approximately 16.7 million colors using RGB 6-bit + HiFRC technology, ensuring high-quality visuals while balancing system cost and performance.
Additionally, the G190ETN01.4 uses a dual-channel LVDS interface, making it compatible with a variety of industrial-grade host platforms. The module features a built-in LED backlight system but does not include touch functionality; if touch operation is required, an external touch solution must be integrated.
G190ETN01.4 Specifications
We will now present a detailed parameter list of the G150XTN03.5 LCD module, highlighting its key technical specifications, including screen size, resolution, panel type, backlight system, interface, and other electrical characteristics.
TYPE | DESCRIPTION |
Brand | AUO |
Model | G190ETN01.4 |
Size | |
Composition | LCM |
Resolution | 1280(RGB)×1024, SXGA 86PPI |
Luminance | 450 cd/m² (Typ.) |
Contrast Ratio | 1000:1 (Typ.) (TM) |
Viewangle | 85/85/80/80 |
Color Depth | 16.7M 90% NTSC |
Light Source | WLED [4 strings] , 50K hours , With LED Driver |
Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
Pixel Format | RGB Vertical Stripe |
Active Area | 379.72(W)×304.46(H) mm |
Frame Rate | 60Hz |
Touchscreen | Without |
Voltage Supply | 5.0V (Typ.) |
Weight | 1.80Kgs (Typ.) |
Outline Size | 396(H)×324(V)×13.38(D) mm |
Max Ratings | Operating Temperature:-30 ~ 85 °C ; Storage Temperature: -30 ~ 85°C |
G190ETN01.4 Mechanical and Optical Characteristics
Understanding the mechanical and optical characteristics of the G190ETN01.4 is equally important when selecting and designing display systems. This will help engineers with considerations for device integration and interface design.
1. Physical Dimensions and Active Area
This module features a classic 5:4 aspect ratio, providing a substantial 376.32 x 301.056 mm active display area. Its overall outline dimensions are 396.0 x 324.0 x 17.5 mm, making it a drop-in replacement for many standard 19-inch rack-mount and industrial HMI enclosures.
2. Pixel Pitch and Display Density
With a native resolution of 1280 x 1024 (SXGA), the panel offers a precise pixel pitch of 0.294 x 0.294 mm. This translates to approximately 86 PPI (Pixels Per Inch), delivering a balanced pixel density.
3. Advanced Surface Treatment
The G190ETN01.4 LCD panel is equipped with an Anti-glare (AG) surface treatment. This matte finish, combined with a 3H Hard Coating, significantly reduces specular reflections and protects the sensitive liquid crystal layer from minor scratches and environmental wear.
4. Display Mode and Visual Performance
The module operates in TN (Twisted Nematic) Mode, which is typically favored in industrial settings. It achieves a high contrast ratio of 1000:1 and a brightness of 450 nits, so the critical data always remains sharp and distinguishable.
G190ETN01.4 Display Advantages & Limitations
In this part, we will introduce the core competitive advantages of the G190ETN01.4 industrial LCD module and its limitations in specific applications.
Advantages
l High Reliability for 24/7 Operations: Its built-in backlight has a lifespan of up to 50,000 hours for consistent brightness and reliable display.
l Superior Visuals in Bright Environments: With a high brightness of 450 cd/m², the module provides clear visibility and allows operators to quickly read critical information without strain.
l Classic 4:3 Aspect Ratio: Featuring a 4:3 standard aspect ratio, the G190ETN01.4 perfectly fits legacy HMI software and financial system interfaces, enabling seamless integration without the need to redesign the UI.
l Replaceable LED Driver: The module comes with an integrated LED driver circuit, simplifying system design and integration. When needed, the LED driver can be replaced easily, enhancing maintenance and upgrade flexibility.
Limitations
l Vertical Viewing Angle (TN Panel): Using TN (Twisted Nematic) technology, this model offers slightly lower color consistency in the vertical direction compared to high-end IPS panels.
l Resolution Specificity (Classic SXGA): The SXGA resolution is tailored for industrial HMI and legacy software interfaces. When displaying 16:9 HD video, black bars may appear at the top and bottom.
G190ETN01.4 Application Areas
The G190ETN01.4 display panel features a large size, high brightness, and industrial-grade reliability, making it particularly suitable for various industrial display scenarios. This module provides a clear and stable display effect, supporting the efficient operation and safe management of industrial systems.
1. Industrial Control Panels
With high brightness and wide temperature tolerance, the G190ETN01.4 is ideal for industrial control panel displays. The module provides stable visual output, helping operators monitor equipment status and production parameters in real time, improving both efficiency and safety.
2. Equipment Operation Interfaces
In automated production lines or machinery, the G190ETN01.4 can serve as an operation interface, displaying control commands, status information, and alerts in real time.
3. Monitoring and Data Visualization
This module is suitable for industrial monitoring systems, showing key data, sensor information, and production metrics. It supports remote monitoring and data analysis, enhancing the accuracy and efficiency of industrial management.
4. Instrument and Meter Displays
The SXGA resolution and square display area of G190ETN01.4 make it well-suited for industrial instruments, testing equipment, or energy management systems, ensuring clear and readable interface information.
5. Embedded Industrial Devices
Its compact design and low power consumption make the module an ideal choice for embedded industrial devices. Whether for portable testing instruments, medical equipment, or smart control terminals, it delivers reliable display performance.
6. Industrial Outdoor Equipment
For industrial applications requiring outdoor use, such as weather monitoring stations or energy device displays, the G190ETN01.4's high-brightness backlight and wide temperature range ensure clear visibility even under strong sunlight or harsh environmental conditions.
What to Consider When Using It?
1) Handle the front polarizer carefully to avoid scratches.
2) Always turn off power before connecting or disconnecting the module.
3) Wipe off any water immediately to prevent discoloration or spots.
4) Clean the panel with soft cloth or absorbent cotton when soiled.
5) The panel is glass—avoid drops or strong impacts.
6) Ground yourself to prevent ESD damage before handling.
7) Do not open or modify the module.
8) Avoid pressing the reflector sheet at the back.
9) When repacking, press the LED light bar edges gently, not the center.
10) Do not rotate or tilt the signal interface connector during insertion or removal.
11) Avoid twisting or bending the module; protect it from external force.
12) Ensure power supply meets Limited Power Source requirements; module materials are non-flammable.
13) Continuous operation in high temperatures may shorten backlight life and reduce brightness.
14) Avoid static images for long periods to prevent image sticking; use screen savers or periodically change content.
FAQs
What is the display size and resolution of G190ETN01.4?
The module features a 19.0-inch TFT-LCD panel with SXGA resolution (1280 × 1024 pixels).
What type of panel does it use?
G190ETN01.4 uses a TN (Twisted Nematic) TFT-LCD panel for fast response and reliable industrial performance.
What is the interface type?
It uses a dual-channel LVDS interface, compatible with most industrial-grade control platforms.
What precautions should be taken during handling?
Avoid scratches on the polarizer, prevent static discharge (ESD), do not twist or bend the module, and ensure the power is off when connecting or disconnecting the interface.
