NL192108AC13-02D 11.6" FHD eDP LCD Specs & Uses
NL192108AC13-02D Introduction
NL192108AC13-02D is an 11.6-inch a-Si TFT-LCD display panel for industrial applications. It features an integrated WLED backlight system with a built-in LED driver, providing stable brightness performance and simplified system integration. The panel adopts a matte surface treatment to help reduce glare.
It supports both a wide operating and storage temperature range of -20°C to 70°C. It also offers vibration resistance up to 2.0G (19.6 m/s²), making it suitable for applications requiring reliable long-term display performance.
NL192108AC13-02D Specifications
The NL192108AC13-02D display features stable display performance. We will provide a detailed table of this model's key technical specifications, assisting engineers in quickly understanding its performance and compatibility.
TYPE | DESCRIPTION |
Brand | NLT |
Model | NL192108AC13-02D |
Size | |
Composition | LCM |
Resolution | 1920(RGB)×1080, FHD 190PPI |
Luminance | 450 cd/m² (Typ.) |
Contrast Ratio | 1000:1 (Typ.) (TM) |
Viewangle | 88/88/88/88 |
Color Depth | 16.7M 70% NTSC |
Light Source | WLED , 30K hours , With LED Driver |
Interface Type | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
Pixel Format | RGB Vertical Stripe |
Active Area | 259.71(W)×147.97(H) mm |
Frame Rate | 60Hz |
Touchscreen | Without |
Voltage Supply | 3.3V (Typ.) |
Weight | 450/500g (Typ./Max.) |
Outline Size | 276.5(W)×165.6(H) ×6.5(D) mm |
Vibration Level | 2.0G (19.6 m/s²) |
Max Ratings | Operating Temperature:-20 ~ 70 °C ; Storage Temperature: -20 ~ 70°C |
NL192108AC13-02D Structure and Principle
Color LCD module NL192108AC13-02D is composed of the amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure with driver LSIs for driving the TFT (Thin Film Transistor) array and a backlight.
The a-Si TFT LCD panel structure is injected liquid crystal material into a narrow gap between the TFT array glass substrate and a color-filter glass substrate. Color (Red, Green, Blue) data signals from a host system (e.g. signal generator, etc.) are modulated into best form for active matrix system by a signal processing board, and sent to the driver LSIs which drive the individual TFT arrays.
The TFT array as an electro-optical switch regulates the amount of transmitted light from the backlight assembly, when it is controlled by data signals. Color images are created by regulating the amount transmitted light through the TFT array of red, green and blue dots.
NL192108AC13-02D Features and Advantages
As a high-performance LCD module, the NL192108AC13-02D offers significant advantages for optical performance, system integration, environmental adaptability, etc. This part will focus on its core features and key highlights.
l Ultra-wide viewing angle: Provides a wide viewing experience, maintaining clear and stable colors from different viewing angles.
l Wide color gamut performance: Delivers richer colors and more natural gradients.
l Wide operating temperature range: Ensures stable operation in both high and low temperature environments.
l High-speed eDP interface: Adopts an eDP interface with higher transmission efficiency and simpler wiring.
l 8-bit RGB signal support: Provides smoother color transitions and more detailed image rendering.
l Built-in LED driver backlight: Integrates WLED backlight with a built-in driver circuit to reduce design complexity.
l Safety and compliance certification: Complies with UL60950-1 / CSA safety standards.
l RoHS compliance: The panel complies with the European RoHS directive, restricting the use of hazardous substances.
NL192108AC13-02D Limitations
Despite the exceptional display performance of the NL192108AC13-02D, it still presents the following three limitations in practical applications:
l No touch function: This module is a display-only LCD panel and does not feature an integrated touch screen.
l High power consumption and thermal constraints: To achieve industrial-grade levels of brightness and contrast, the power consumption of its backlight and driver circuitry is significantly higher than that of standard commercial displays.
NL192108AC13-02D Application Fields
Based on its advantages and specifications, the NL192108AC13-02D is suitable for a wide range of industrial applications, including industrial control, embedded systems, and more.
Industrial Automation Control Systems
This display panel serves as a core HMI display module, widely applied in PLC control cabinets, production line terminals and industrial operation panels to support round-the-clock factory operation.
Industrial Test & Measurement Equipment
Model NL192108AC13-02D fits oscilloscopes, signal analyzers, ATE and DAQ systems, enabling engineers to conduct accurate data analysis and evaluation.
Medical Electronic Devices
It is adopted as the human-machine interface for patient monitors, diagnostic and testing instruments, allowing medical staff to read core data clearly from various viewing angles.
Transportation & Railway Industrial Systems
The panel is also suitable for subway control consoles, locomotive display terminals and signal dispatching systems, maintaining stable operation under severe vibration and temperature fluctuation.
Industrial Embedded Computing & Control Devices
This LCD panel is commonly used in all-in-one industrial controllers, embedded terminals, SCADA systems and power distribution monitoring interfaces, delivering reliable display solutions for industrial digitalization and energy visualization.
NL192108AC13-02D Datasheet
Compatible Solutions for NL192108AC13-02D
Evaluating compatible replacements for the NL192108AC13-02D requires strict matching of mechanical size, interface, and electrical parameters.
For direct pin-to-pin replacements, closely related models from the same Tianma/NEC family, such as NL192108AC13-02C or NL192108AC13-02E, are often used.
When cross-brand alternatives are required, industrial-grade 11.6-inch FHD panels from manufacturers such as AUO G116HAN01.0.
FAQs
What type of display is NL192108AC13-02D?
It is an 11.6-inch a-Si TFT-LCD industrial panel with Full HD (1920×1080) resolution from NTL for industrial display systems.
What is the operating temperature range?
It supports a wide industrial temperature range of approximately -20°C to +70°C, making it suitable for both indoor and semi-harsh environments.
Is it suitable for long-term industrial use?
Yes, it is designed for continuous operation with stable performance, making it ideal for 24/7 industrial environments such as HMI systems and monitoring platforms.
Does it support touch inputs?
No, this specific model is a pure display panel (Without Touchscreen). If your application requires an HMI touch interface, you will need to source and calibrate an external capacitive or resistive touch overlay.
