LQ150X1LX95 Overview
The LQ150X1LX95 is a 15.0-inch diagonal a-Si TFT-LCD display panel developed by Sharp Corporation. As a color active matrix LCD module based on amorphous silicon (a-Si) TFT technology, it is designed to deliver stable image performance and reliable operation in professional display applications. The module features an XGA resolution of 1024 × RGB × 768 pixels, supporting approximately 16 million colors for clear graphics and detailed text presentation.
This LCD module integrates a color TFT-LCD panel, driver ICs, control circuit, power supply circuit, and a White-LED backlight unit into a complete display solution. It utilizes an LVDS (Low Voltage Differential Signaling) interface for high-speed and low-noise data transmission, requiring +3.3V DC for panel driving and +12.0V DC for the backlight system. The panel offers high brightness and high contrast performance, while the built-in LED driver circuit simplifies system integration and enhances overall reliability.
LQ150X1LX95 Technical Specifications
Below is a detailed reference table summarizing the key technical specifications and performance parameters of the Sharp LQ150X1LX95 LCD panel.
TYPE | DESCRIPTION |
Brand | Sharp |
Model | |
Size | |
Composition | a-Si TFT-LCD, LCM |
Resolution | 1024(RGB)×768, XGA 85PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 304.128(W)×228.096(H) mm |
Bezel Opening | 307.4(W)×231.3(H) mm |
Outline Size | 326.5(W)×253.5(H)×10.1(D) mm |
Brightness | 400 cd/m² (Typ.) |
Contrast Ratio | 1500:1 (Typ.) (TM) |
Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
Response Time | 35 (Typ.)(Tr+Td) |
Display Colors | 262K/16.2M 70% NTSC |
Lamp Type | WLED , 70K hours , With LED Driver |
Frequency | 60Hz |
Voltage Supply | 3.3V (Typ.) |
Panel Weight | 950g (Max.) |
Signal Interface | · LVDS (1 ch, 6/8-bit) , 20 pins Connector |
Touchscreen | Without |
Max Ratings | Operating Temperature:-20 ~ 70 °C ; Storage Temperature: -25 ~ 70°C |
LQ150X1LX95 LCD Module Structure
Here is a detailed breakdown of the four core components of the SHARP LQ150X1LX95 industrial-grade LCD module:
1. TFT-LCD Panel
The TFT panel consists of liquid crystal molecules sandwiched between two sheets of ultra-thin glass, integrated with millions of thin-film transistor switches. It is responsible for precisely controlling the light transmission of each pixel to render high-definition XGA (1024 x 768) images.
2. Driving Circuitry
The core component of the driving circuitry, the TCON (Timing Controller), receives raw image signals from the host and converts them into electrical signals that the liquid crystal molecules can recognize. By precisely controlling the Source and Gate driver ICs, the circuit instantaneously adjusts the voltage of every individual pixel.
3. Backlight System
Since the LCD panel does not emit light on its own, it relies on a WLED (White Light Emitting Diode) strip at the bottom as a light source. This light is passed through a light guide plate and multiple diffusion sheets to transform it into a uniform surface light source.
4. Interface Type
This module typically utilizes an LVDS (Low Voltage Differential Signaling) interface, which is the standard connection method for modern industrial displays. This interface possesses superior EMI (Electromagnetic Interference) resistance, ensuring the total integrity of signal transmission.
LQ150X1LX95 Display Performance
Brightness & Contrast Ratio
This module features an industrial-grade high brightness of 450–500 cd/m². Combined with a high contrast ratio of 800:1, it effectively enhances the sharpness of character and graphic outlines, significantly reducing operator eye fatigue during extended use.
Color & Gray Scale Performance
The panel supports a color depth of 16.2M (6-bit + FRC), ensuring exceptionally smooth color transitions without banding. Thanks to precise grayscale control technology, the module delivers high-fidelity image reproduction, even when displaying complex 2D/3D data charts and diagrams.
Response Time & Viewing Angle
Featuring a fast dynamic response time of 8ms (Typ.), this display ensures no ghosting or motion blur when playing real-time surveillance footage or dynamic waveform graphs. With wide viewing angles of 85°/85°/85°/85° (Typ.), it maintains consistent color and image integrity from almost any perspective.
LQ150X1LX95 Interface and Compatibility
The module is equipped with a standard LVDS (Low Voltage Differential Signaling) interface, supporting both single and dual-channel data transmission. This architecture enables high-bandwidth image data synchronization with minimal power consumption. In industrial environments, the LVDS differential balanced design effectively resists ambient noise, preventing screen flickering and signal noise.
In terms of system integration, the module offers seamless, driver-free compatibility with mainstream industrial motherboards on the market. Depending on the application, it can be quickly converted to standard VGA, HDMI, or DisplayPort (DP) signals by pairing it with a dedicated controller board. This versatility significantly simplifies hardware development and provides flexible options for future system upgrades.
LQ150X1LX95 Industrial Applications
The LQ150X1LX95 TFT-LCD panel, with its high brightness, high contrast, and stable LVDS interface, is widely used in industrial control and embedded display applications. Key application scenarios include:
Industrial Automation and Production Line Control
This display is commonly used in PLC control systems, factory automation equipment, and HMI (Human-Machine Interface) panels. It provides real-time visualization of production status, process parameters, and alarm information, enabling operators to monitor and respond to critical conditions efficiently.
Power and Control Cabinet Displays
The LQ150X1LX95 can be integrated into power distribution systems, inverter control cabinets, and intelligent power equipment as a core display module. Its LVDS interface offers strong anti-interference capability, ensuring stable signal transmission and reliable long-term operation in industrial environments.
Construction Machinery and Special Vehicles
In agricultural machinery, construction vehicles, and marine bridge displays, this panel serves as an operational interface. Its 1.5G vibration resistance allows the equipment to withstand continuous shocks and vibrations, making it suitable for harsh industrial conditions.
Industrial Monitoring and Data Acquisition Systems
The LQ150X1LX95 is ideal for displaying industrial sensor data, remote monitoring terminals, and measurement & control equipment. It delivers clear visualization of data curves, charts, and alarm information, supporting real-time monitoring and data analysis.
Embedded Industrial Terminals
This panel is suitable for a wide range of industrial embedded control systems and HMI devices. It supports multi-user operation and wide viewing angles, meeting the demands of long-term operation and complex industrial environments.
FAQs
What resolution does LQ150X1LX95 support?
The LQ150X1LX95 supports XGA resolution of 1024 × 768 pixels, providing a clear image and text display for industrial and embedded applications.
What interface does it use?
This panel uses a single-channel LVDS (Low Voltage Differential Signaling) interface, ensuring stable, low-noise signal transmission and compatibility with most industrial control systems.
Is it suitable for industrial applications?
Yes. The LQ150X1LX95 is designed for industrial environments, featuring high brightness, high contrast, vibration resistance, and long-term operational stability, making it ideal for automation, monitoring, and embedded systems.
What is the typical backlight lifetime?
The module’s White-LED backlight typically lasts up to 50,000–70,000 hours, depending on operating conditions, ensuring long-term reliability in industrial applications.
